Strong Suction Vacuum Lift Crane for Glass and Marble Handling and Installation

1 / 5

Strong Suction Vacuum Lift Crane for Glass and Marble Handling and Installation

Still deciding? Get samples of $ !

Request Sample

Send Inquiry

Product Description

Basic Information

Model NO.

GL-SC

Application

Workshop, Shipboard, Warehouse, Building Crane

Lift Mechanism

Hanging Crane

Driven Type

DC Battery

Certification

GS, CE, RoHS, ISO 9001

Tilting

90 Degree Manual

Lifting Method

Vacuum

Capacity Range

400kg / 600kg / 800kg / 1000kg

Product Description

900Lbs Glass Suction Lifter

Vacuum suction caps are specially designed for handling different kinds of heavy plate, board and glass. They are highly effective for installing steel boards, glass walls, and moving heavy materials such as granite and marble.

Model	Unit	GL-SC-400X	GL-SC-600X	GL-SC-800X	GL-SC-1000X	GL-SC-1200X
Lifting Capacity	kg	400	600	800	1000	1200
Cup Qty	/	4	6	8	10	12
Single Cup Size	mm	300	300	300	300	300
Rotation	/	360° Manual Rotate
Tilting	/	90° Manual
Voltage	V	DC12
Charger	V	AC220/110
Extension Bar	mm	500

Product Gallery

Features & Advantages

Sealed cover for components protection, safe and reliable. Compatible with bridge cranes or cantilever cranes.

Adjustable suction cup positions to accommodate different glass shapes and sizes.

Manual 360° vertical rotation and 90° horizontal rotation; electric taking and releasing.

Equipped with American THOMAS vacuum pump and high-quality maintenance-free battery.

Japan Panasonic digital display vacuum pressure switch and battery fuel gauge for safety monitoring.

Pressure-keeping device ensures stability during power failure, providing extra safety time.

OEM & ODM services available based on material size and weight.

Frequently Asked Questions

What materials can this lifter handle?

It is designed for heavy plates including glass, steel boards, granite, and marble.

Does it require a continuous power supply during operation?

No, it uses a DC12V maintenance-free battery and an integrated vacuum pump, so no external air or power source is needed during use.

How safe is the equipment if the power fails?

The lifter is equipped with a pressure-keeping device and an alarm that maintains suction even if power is lost, allowing for safe handling.

Can the suction cups be adjusted?

Yes, the positions of the suction cups are adjustable to fit various glass dimensions and shapes.

What is the maximum lifting capacity available?

The series ranges from 400kg up to a maximum of 1200kg depending on the specific model.

What kind of rotation does it offer?

It provides 360° manual rotation in the vertical side and 90° manual rotation in the horizontal side.
